The SoM module has a powerful processor and supports high-quality video. It can be customized for different uses.
MYIR has released the MYC-LR3568, an affordable System-on-Module (SoM) featuring the RK3568 from Rockchip—a quad-core ARM Cortex-A55 processor combining high performance and low power consumption. The SoM leverages the powerful Mali-G52 2EE GPU and supports up to 1 TOPs NPU, handling a range of video codecs, including 4K 60fps H.265/H.264/VP9 decoding and 1080P 60fps H.265/H.264 encoding. This ensures superior video quality for both playback and recording.
The SoM is packaged in a compact 381-pin LGA form, measuring 43mm x 45mm, and integrates essential components like the RK3568J/RK3568B2 processor, 2GB LPDDR4 memory, 16GB eMMC storage, EEPROM, and PMIC. It offers customization options, including eMMC capacities (8GB/32GB) and memory sizes (1GB/4 GB/8 GB). The module supports Linux and Debian operating systems, making it suitable for applications such as IoT gateways, industrial control systems, and facial recognition systems.
The company offers the MYD-LR3568 Development Board for development and evaluation, which incorporates the SoM. This board features a carrier design enriched with a wide array of peripherals and interfaces, including USB ports, Gigabit Ethernet, CAN interfaces, and options for WiFi/Bluetooth, alongside various display outputs like HDMI and MIPI-DSI.
Additionally, the board includes a 40-pin RPI-compatible expansion interface and a custom 40-pin expansion interface for further extensibility. Optional modules, such as camera and communication modules, are also available to enhance the board’s capabilities.
Some of the key features of the SoM:
- Dimensions: 43mm x 45mm
- 12-layer PCB design
- Power supply: 5V/1A, 3.3V/3A
- Features up to 1.0 TOPS NPU
- Video capabilities include 4K 60fps decoding and 1080P 60fps encoding
- Memory: 2GB LPDDR4, with options for 1GB/4GB/8GB
- Storage: 16GB eMMC, with options for 8GB/32GB
- Includes 32KB EEPROM
- 381-pin LGA expansion interface
The company claims to provide two standard configurations of the SoM, designed to meet varied customer needs and offers competitive pricing with discounts on bulk purchases.
