Flip-flop Qubits: Radical New Quantum Computing Design Invented

- Advertisement -

UNSW engineers have invented a radical new architecture for quantum computing, based on novel ‘flip-flop qubits’, that promises to make the large-scale manufacture of quantum chips dramatically easier.

Engineers at Australia’s University of New South Wales have invented a radical new architecture for quantum computing, based on novel ‘flip-flop qubits’, that promises to make the large-scale manufacture of quantum chips dramatically cheaper – and easier – than thought possible.

The new chip design, detailed in the journal Nature Communications, allows for a silicon quantum processor that can be scaled up without the precise placement of atoms required in other approaches. Importantly, it allows quantum bits (or ‘qubits’) – the basic unit of information in a quantum computer – to be placed hundreds of nanometres apart and still remain coupled.

- Advertisement -

The design was conceived by a team led by Andrea Morello, Program Manager in UNSW-based ARC Centre of Excellence for Quantum Computation and Communication Technology (CQC2T), who said fabrication of the new design should be easily within reach of today’s technology.

Lead author Guilherme Tosi, a Research Fellow at CQC2T, developed the pioneering concept along with Morello and co-authors Fahd Mohiyaddin, Vivien Schmitt and Stefanie Tenberg of CQC2T, with collaborators Rajib Rahman and Gerhard Klimeck of Purdue University in the USA.

“It’s a brilliant design, and like many such conceptual leaps, it’s amazing no-one had thought of it before,” said Morello.

“What Guilherme and the team have invented is a new way to define a ‘spin qubit’ that uses both the electron and the nucleus of the atom. Crucially, this new qubit can be controlled using electric signals, instead of magnetic ones. Electric signals are significantly easier to distribute and localise within an electronic chip.”

Tosi said the design sidesteps a challenge that all spin-based silicon qubits were expected to face as teams begin building larger and larger arrays of qubits: the need to space them at a distance of only 10-20 nanometres, or just 50 atoms apart.

“If they’re too close, or too far apart, the ‘entanglement’ between quantum bits – which is what makes quantum computers so special – doesn’t occur,” Tosi said.

Morello said researchers at UNSW already lead the world in making spin qubits at this scale. “But if we want to make an array of thousands or millions of qubits so close together, it means that all the control lines, the control electronics and the readout devices must also be fabricated at that nanometric scale, and with that pitch and that density of electrodes. This new concept suggests another pathway.”

Artist's impression of a 'flip flop' qubit in an entangled quantum state. Illustration: Tony Melov
Artist’s impression of a ‘flip flop’ qubit in an entangled quantum state. Illustration: Tony Melov

Artist’s impression of a ‘flip flop’ qubit in an entangled quantum state. Illustration: Tony Melov

At the other end of the spectrum are superconducting circuits – pursued, for instance, by IBM and Google – and ion traps. These systems are large and easier to fabricate, and are currently leading the way in the number of qubits that can be operated. However, due to their larger dimensions, in the long run they may face challenges when trying to assemble and operate millions of qubits, as required by the most useful quantum algorithms.

“Our new silicon-based approach sits right at the sweet spot,” said Morello, a professor of quantum engineering at UNSW. “It’s easier to fabricate than atomic-scale devices, but still allows us to place a million qubits on a square millimetre.”

In the single-atom qubit used by Morello’s team, and which Tosi’s new design applies, a silicon chip is covered with a layer of insulating silicon oxide, on top of which rests a pattern of metallic electrodes that operate at temperatures near absolute zero and in the presence of a very strong magnetic field.

At the core is a phosphorus atom, from which Morello’s team has previously built two functional qubits using an electron and the nucleus of the atom. These qubits, taken individually, have demonstrated world-record coherence times.

Tosi’s conceptual breakthrough is the creation of an entirely new type of qubit, using both the nucleus andthe electron. In this approach, a qubit ‘0’ state is defined when the spin of the electron is down and the nucleus spin is up, while the ‘1’ state is when the electron spin is up, and the nuclear spin is down.

“We call it the ‘flip-flop’ qubit,” said Tosi. “To operate this qubit, you need to pull the electron a little bit away from the nucleus, using the electrodes at the top. By doing so, you also create an electric dipole.”

Dr Guilherme Tosi and Professor Andrea Morello at the UNSW quantum computing labs with a dilution refrigerator, which cools silicon chips down to 0.01 ̊ above absolute zero. Photo: Quentin Jones

“This is the crucial point,” adds Morello. “These electric dipoles interact with each other over fairly large distances, a good fraction of a micron, or 1,000 nanometres.
